Parameter	Value	Parameter	Value	Parameter	Value
Model	JAC-T30 (CPCD30J)	Rated Load	3,000 kg (6,614 lb) @ 500 mm Load Center	Lift Height (Std Mast)	3,000 mm (9.8 ft)
Overall Dimensions (L×W×H)	2,789 × 1,230 × 2,120 mm	Wheelbase	1,700 mm	Min. Turning Radius	2,500 mm (8.2 ft)
Curb Weight	4,300 kg (9,480 lb)	Engine Model	ISUZU C240 NK FG-01 (Diesel) / Yanmar 4TNE98	Rated Power	34.3 kW (46 HP) @ 2,500 RPM
Max. Travel Speed (Loaded)	19 km/h (11.8 mph)	Hydraulic Lift Speed	0.465 m/s (18.3 in/s)	Free Lift Height	155 mm (6.1 in)
Tire Specification	Front: 28×9-15-14PR / Rear: 6.50-10-10PR	Wheel Track (F/R)	1,000 mm / 970 mm	Ground Clearance	130 mm (5.1 in)
Transmission	5-Speed Manual w/ Torque Converter	Brakes	Dual Hydraulic Disc (Front) / Drum (Rear)	Battery (Optional)	12V/80Ah (For Auxiliary Systems)
Mast Tilt Angle (Fwd/Back)	6° / 12°	Fork Dimensions	1,220 × 125 × 45 mm (L×W×T)	Gradeability (Loaded)	20%
Cab Features	ROPS-Compliant, Adjustable Seat/Steering	Maintenance Interval	500 Hours	Fuel Tank Capacity	60 L (15.9 gal)
Optional Configurations	Triplex Mast (5,000 mm Lift), CNG Conversion	EMission Standard	China III (Euro 3 Equivalent)	HS Code	8427209000

High Quality Used JCB-T30 Mini Telehandler Compact Machine
